| BRAND | Stübbe |
| Product | ET 50-125 |
| Description | Eintauchpumpe |
| Internal code | IMP1490165 |
| Weight | 110 |
| Technical specification | Eintauchpumpe ET 50-125 PP-EPDM **Pumpe nach Seriennr.: 34300** Eintauchtiefe: 2000mm Anschluss: Verschraubung Bogen Schrauben: PVDF 150 / 24,00 / Geschlossen; mit Entlastungsbohrung Zwischenlager: ja Gleitwerkstoffe: SSiC / PTFE-Carbon +++++++++ i n c l. +++++++++ Motor Normwelle Nennleistung 50 Hz:5.5 kW Nennleistung 60 Hz:6.3 kW Synchrondrehzahl 50 Hz 3000 U/min Synchrondrehzahl 60 Hz 3600 U/min Spannung [V] bei Dreieck 50 Hz 400V Spannung [V] bei Stern 50 Hz 690V Spannung [V] bei Dreieck 60 Hz 460V 112M B14 C200 IP55 F IE2 Festlager: B-Seite PTC Kaltleiter: 3 PTC FU Betrieb möglich bis 500V RAL7016 Anthrazitgrau **Pumpe nach Seriennr.: 34300** Förderstrom:30 m³/h Förderhöhe:20 m Medium:Washing water Konzentration:5% Temperatur:20 °C Spezifische Dichte:1 kg/dm³ Viskosität:1 mm²/s Laufraddurchmesser:150 mm Leistung:5,5 kW Synchrondrehzahl:3.000 1/min Spannung:400 / 690 V Frequenz:50 Hz |
Temui kualiti dan prestasi unggulStübbe ET 50-125 denganImpexron GMBH dalamIreland . Sama ada anda mencari kebolehpercayaan atau kecekapan, produk ini memenuhi semua keperluan industri anda.
TheET 50-125 direka untuk memberikan prestasi optimum dan ketahanan dalam pelbagai aplikasi. Dikenali dengan pembinaan berkualiti tinggi dan ciri-ciri inovatif, ia adalah pilihan utama untuk profesional.
Ciri-ciri UtamaET 50-125 :
PadaImpexron GMBH , kami menawarkanET 50-125 pada harga yang kompetitif dan dengan masa penghantaran terpantas di seluruhIreland . Pasukan pakar kami bersedia untuk membantu anda dengan semua pertanyaan anda dan menyediakan penyelesaian yang disesuaikan untuk memenuhi keperluan khusus anda.
Mengapa MemilihImpexron GMBH ?
Dapatkan Sebut Harga Anda Hari Ini! Bersedia untuk meningkatkan operasi anda denganET 50-125 ? Hubungi kami sekarang untuk sebut harga yang diperibadikan. Isi borang di bawah atau hantarkan e-mel kepada kami dengan pertanyaan anda. Biar kami membantu anda membuat pilihan yang menjimatkan kos dan dipacu kualiti untuk perniagaan anda.
Notis Penting: Semasa kami membekalkanStübbe produk,Impexron GMBH bukan pengedar sah . Semua hak adalah terpelihara oleh pengilang dan rakan kongsi rasmi mereka.
You can purchase :product by :brand from Impexron GMBH.We serve customers across the Ireland, offering competitive prices and reliable service.
What is the price of :product?
For customised pricing and availability, please fill out our or give us a call. We are dedicated to providing solutions that align with your specific requirements.
While we are not the official distributor or seller of :brand in the Ireland, we source our products from reliable channels and offer you original :brand equipment at competitive prices.
You can access catalogues, user manuals, and technical documents for :product on our website. Visit our resources section or contact us directly for specific documents.
We can assist you in contacting the manufacturer to ensure you receive the support you need.
