SV8006HCFMFG0200NN - STRAHMAN VALVES Ireland Sales

BRAND	STRAHMAN VALVES
Product	SV8006HCFMFG0200NN
Description	Soft seated piston valve, Soft Seal. S Series
Internal code	IMP1136042
Weight	1
Technical specification	SV-800 1 "/ 3/4 " - 600 lbs Class ANSI 600 lbs ASTM A351-CF8M (316) Trim 316SS Extended Plunger According Drawing N° SV brochure Sealing System : Seat Type '' Soft Seal ® '', Special Seat Graphite Packing Graphite Application : Service : Sampling Process : advise Fluid : advise Design Conditions : Pressure : 60 bars / 858 psi Temperature : 100° C / 212° F Actuation : Crank Handle with opening indicator The valve actuator is sized to operate against a working pressure of 10 bar / 150 psi Connections : Inlet : 1" NPT-M Plunger Diameter 20 mm/0.8 Inche(s) ,Extention 50.8 mm/2 Inche(s) Branch Angle 60° Branch : 3/4 "NPT F Included Options: None Quality Control Testing : NDE (LPT) and Function Included Tests: Hydrostatic (API 598 / B 16.5) Included

Please Contact Us to Order to offer competitive prices and delivery time for STRAHMAN VALVES - SV8006HCFMFG0200NN Soft seated piston valve, Soft Seal. S Series number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Ireland Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
